Front Runner Retrax XR Double Load Bar Kit 5" 2005-Current Fits Toyota Tacoma

Product Description

Info

• Custom Fit for 2005-Current Toyota Tacoma – Designed to seamlessly fit ReTrax XR rails for quick, drill-free installation.
• Low-Profile Design – Maintains the truck’s sleek appearance while maximizing cargo space.
• Preserves Load Bed Capacity – Allows full use of the truck bed for transporting larger items without obstruction.
• Drop-Down Door Functionality – Ensures the tailgate remains fully operational for easy access to the load bed.
• Durable and Secure – Built to securely carry gear and withstand tough conditions, perfect for both adventure and daily use.

Specs

Kit Components:

• 2x LASS028 - Pick-Up Roll Top Leg Mount
• 1x LBSK016 - Roof Load Bar Pair 1425mm (W)

Material & Build:

• Frame: Black epoxy powder-coated T6 aluminium

Weight & Compatibility:

• Installed Weight: Approx. 6kg (13.23lbs)
• T-Slot Compatibility: The t-slots on the tops and bottoms of the slats accommodate standard 8mm bolts.

Height Adjustments:

• Determine Rack Height:
  • Load Bar Kit Only: Add 22mm (7/8") to the height of the Foot, Grab-On Foot.
  • With Legs: Add 22mm (7/8") to the height of the Legs to determine the rack height from the vehicle’s rain gutters.
  • With Foot Rails: Add 22mm (7/8") to the height of the Foot Rails to determine the rack height from the highest point of the vehicle’s roof.

Shipping Details:

• Dimensions:
  • Width: 170mm (7")
  • Length: 1540mm (61")
  • Height: 160mm (6")
• Shipping Weight: Approx. 9kg (20lbs)

Installation Instructions

Installation.pdf
